TS-DO12WNA/TS-DO18WNA
Technical Datas:
Product code: TS-DO30WD
Power (wattage): 30W
Cut-out: Φ125MM
Size: Φ132xH127MM
Adjustable: Yes
Beam angle: 15°, 24°, 38°
IP Rate: IP40
Reflector color: Black/ White
Input voltage: 220-240V AC 50/60HZ OR 85-265VAC
LED Driver: Lifud / Eaglerise / Philips / Osram
Flicker Free: Yes
Anti Glare: Yes
Dimmable: Avaliable (Triac, 0-10V, Dali)
LED source: COB (Bridgelux, CREE, Philips)
Light Color: (27/30/40/50/60) x100K Warm/ Neutral / Cool
LED Lumens: 3000lm+/-3%
LED CRI: >95Ra
Body Color: White / Black
Materials: Aluminium body + Reflector
Operating Temp.: -30 ~ 75℃
Life Span: 50000 Hours
Cetificates: CE-EMC, CE-LVD, RoHS, FCC, C-tick
 |
 |
 |
 |
Other related items
| Model No. | TS-DO12WD | TS-DO20WD | TS-DO30WD |
| Wattage | 12W | 20W | 30W |
| Cut-out | Φ75mm | Φ95mm | Φ125mm |
| Input Voltage | 85-265V AC 50/60 Hz | ||
| Power Factor | PF > 0.95 | ||
| LED Source | Bridgelux / Philips / Cree COB chip |
||
| CCT | Warm White (2700-3500K), Neutral White(4000-4500K), Cold White(5000-6500K) | ||
| Lumens | 1200lm | 2000lm | 3000lm |
| CRI | CRI > 80 (Ra) | ||
| Beam Angle | 15° / 24°/ 38° | ||
| LED Driver | Lifud / Eaglerise / Philips / Osram Brand | ||
| IP Rate | IP40 | ||
| Material | Aluminium Body + Reflector | ||
| Size | D85*H80mm | D104*H108mm | D132*H127mm |
| Body Color | White / Black | ||
| Operating Temp. | -30℃ ~ 75℃ | ||
Select the Right Color Temperature: Choose a color temperature that suits your space. Warm white (2700K-3000K) creates a cozy atmosphere, while cool white (4000K-5000K) is ideal for task-oriented areas.
Consider Beam Angle: The beam angle determines the spread of light. A narrower beam (15°-30°) is suitable for accent lighting, while a wider beam (60°-90°) is perfect for general illumination.
Plan the Layout: Space downlights evenly throughout your room to ensure uniform illumination. Consider using a mix of task, accent, and ambient lighting for a well-lit space.
Hire a Professional: Installing downlights involves working with electrical wiring. It is highly recommended to hire a professional electrician to ensure a safe and successful installation.
30W LED COB downlights with 95mm holes offer an energy-efficient and versatile lighting solution for various applications. By understanding their features, benefits, and installation tips, you can create a well-lit, stylish, and inviting space. Whether you are renovating your home or designing a new office, these downlights are a wise investment that will pay off in the long run.
