TS-DO12WNA/TS-DO18WNA
Dimmable recessed LED Can Lights replacement supplier
our Dimmable Recessed LED Can Lights Replacement. Available in a range of wattages including 12W, 20W, 30W, 40W, and 50W, these lights are here to redefine your lighting experience. With their dimmable feature, you have complete control over the ambience, allowing you to create the perfect lighting for any occasion. Designed to seamlessly replace your existing recessed can lights, they effortlessly blend into your space, providing a sleek and modern look. Not only do these LED lights offer exceptional brightness and versatility, but they are also energy-efficient, helping you save on electricity bills. Upgrade your lighting game with our Dimmable Recessed LED Can Lights Replacement and illuminate your space with confidence and style.
 |
 |
 |
 |
 |
| 12W | 20W | 30W | 40W | 50W |
| Code | TS-DO12WF | TS-DO20WF | TS-DO30WF | TS-DO40WF | TS-DO50WF |
|---|---|---|---|---|---|
| Rated Power | 12W | 20W | 30W | 40W | 50W |
| Cut-Out | D 75MM | D90MM | D125MM | D165MM | D200MM |
| Input Current | 55mA@220V | 91mA@220V | 136mA@220V | 182mA@220V | 227mA@220V |
| Lumens | 1200lm +/-5% | 2000lm +/-5% | 3000lm +/-5% | 4000lm +/-5% | 5000lm +/-5% |
| Beam Angle | 12°, 24°, 38°,55° | 12°, 24°, 38°,55° | 12°, 24°, 38°,55° | 12°, 24°, 38°,55° | 12°, 24°, 38°,55° |
| Size | D85xH55MM | D101xH60MM | D140XH73MM | D180xH94MM | D212xH110MM |
| Products Name |
LED Dimmable recessed ceiling light downlights |
|---|---|
| Body Color | Sandy White / Sandy Black |
| Reflector Color | Matte Black/ Matte White / Matte Silver/ Black / White |
| Materials | Aluminium Body + Reflector |
| IP Rate | IP44 |
| Add Honeycomb | Available |
| Anti-glare | Yes |
| UGR | <19 |
| Flicker Free | Yes |
| Installation | Recessed Type |
| Certificates | CE-EMC, CE-LVD, RoHS, FCC, C-tick |
| Working Voltage | 220-240VAC / 100-277VAC |
|---|---|
| Frequency | 50/60Hz |
| Power Factor(PF) | >0.5 / >0.9 |
| Driver Brand | Philips, Osram, Lifud, Eaglerise, Kegu, Philips |
| Dimmable | Non-DIM / TRIAC / 0-10V / Dali / Push Dimming |
| Total Harmonic Distortion(THD) | ≤15% |
| Color Temperature | 27/30/40/45/50/60K Warm White/Neutral White/ Day White/ Cool White |
|---|---|
| Lighting Efficiency | 120lm/W |
| COB Brand | Bridgelux, CREE, Philips |
| Color Render Index | Ra>80 / Ra>90(Default) / Ra>95 |
| SDCM | <5 |
| Anti Glare | Yes, (UGR<19) |
| Flicker Free | Yes |
