TS-DO12WNA/TS-DO18WNA
Technical Datas:
Product code: TS-DO25WECOB
Power (wattage): 25W
Cut-out: Φ120MM
Size: Φ135xH63MM
Beam angle: 15°, 24°, 36°, 50°
IP Rate: IP40
Reflector color: Matte Black/ Matte White / Matte Sliver/ Gun Black/ Gloden
Input voltage: 220-240V AC 50/60HZ OR 85-265VAC
LED Driver: Lifud / Eaglerise / Philips / Osram
Flicker Free: Yes
Anti Glare: Yes
Dimmable: Avaliable (Triac, 0-10V, Dali)
LED source: COB (Bridgelux, CREE, Philips)
Light Color: (27/30/40/50/60) x100K Warm/ Neutral / Cool
LED Lumens: 2500lm+/-3%
LED CRI: >95Ra
Body Color: White / Black
Materials: Aluminium body + Reflector
Operating Temp.: -30 ~ 75℃
Life Span: 50000 Hours
Cetificates: CE-EMC, CE-LVD, RoHS, FCC, C-tick
 |
 |
 |
 |
| Model No. | TS-DO12WECOB | TS-DO15WECOB |
TS-DO25WECOB | TS-DO30WECOB |
| Wattage | 12W | 15W | 25W | 30W |
| Cut-out | Φ75mm | Φ95mm |
Φ120mm | Φ145mm |
| Input Voltage | 85-265V AC 50/60 Hz | |||
| Power Factor | PF > 0.95 | |||
| LED Source | Bridgelux / Philips / Cree COB chip |
|||
| CCT | Warm White (2700-3500K), Neutral White(4000-4500K), Cold White(5000-6500K) | |||
| Lumens | 1200lm | 1500lm | 2500lm | 3000lm |
| CRI | CRI > 80 (Ra) | |||
| Beam Angle | 15° / 24°/ 36°/ 50° | |||
| LED Driver | Lifud / Eaglerise / Philips / Osram Brand | |||
| IP Rate | IP40 | |||
| Material | Aluminium Body + Reflector | |||
| Size | D85*H48mm | D105*H55mm |
D135*H63mm | D160*H68mm |
| Body Color | White / Black | |||
| Operating Temp. | -30℃ ~ 75℃ | |||
LED downlights are one of the most popular and versatile lighting options for your home or business. They can provide bright, even, and energy-efficient illumination for any space. However, not all LED downlights are the same. There are different types, sizes, shapes, and features that you need to consider when choosing the best ones for your needs. In this article, we will focus on 25W COB fire rated LED downlights, which are some of the most advanced and safe LED lights on the market. We will explain what they are, what are their benefits, and how to find the best manufacturer from China.
COB stands for chip-on-board, which means that the LED chips are directly mounted on a circuit board, creating a single light source. This allows for better heat dissipation, higher brightness, and more uniform light distribution than traditional SMD LEDs. 25W COB fire rated LED downlights are downlights that use this technology and have a power consumption of 25 watts.
Fire rated means that the lights have passed rigorous tests and standards to ensure that they can resist fire and prevent its spread in case of an emergency. Some LED lights may not have this feature and may pose a fire hazard if they overheat or malfunction. Fire rated lights have a special design and material that can withstand high temperatures and flames for up to 90 minutes without compromising their performance or safety.
